PB - Pnömatik dönmeli bağlama clamp

Pnömatik dönmeli bağlama clamp PB
- Max. operating pressure: 7 bar
- Min. operating pressure: 4 bar
- Double acting

 Sipariş kot endikasyonu:


   PB  –--   S   4   R   90° S1






  L: Long stroke

  S: Short stroke

Cylinder inside diameter



Rotating direction

Turn right or turn left

Rotating angle

Standard angle 90°

Order angle 0°,45°,60°

Sensor switch

  S1:1 pc of S1

  S2:2 pcs of S2



This product is perfect , design in brief,the structure is compact,the weight is light,the service life is long and holding capacity is strong. Two types available--- long stroke and short stroke . Fixing from top , base or the side of cylinder is ok. Be applied in industry automatization. clipping of foil, clipping and transporting of work piece on the conveyer belt, main used for packing pipelining.

When you need to increase the length of the clamping arm, please don't exceed 1.5 times of  the original length.
